Basic Ridge Vent Cupola
Basic Ridge Cupola with Louver Blades
Available in Copper, Lead Coated Copper, Freedom Gray® and Stainless Steel
This basic ridge cupola can be manufactured to any pitch, from 0" to 12". It features louver blades that can be completely shut (for decoration only) or open with bug screen to allow for ventilation.
This product is custom made to order by our craftsmen and may not be returned.
Some seams are soldered and some portions are riveted.
Custom designs, sizes and different materials may be available. Please contact us for pricing.
We do not manufacture wooden bodies for cupolas, but our craftsmen can outfit new customer supplied wooden cupolas with metal roofs. Made in the USA.
Materials
- Copper - 16 oz. and 20 oz.
- Freedom Gray® - 16 oz. and 20 oz.
- Lead Coated Copper - 16 oz. and 20 oz.
- Stainless Steel - 2B 304 24 gauge
Specifications
- Base width: 25" x 25" (+6" Mounting flange)
- Base height: 16"
- Total height: 32.4"
- Pitch: 0", 1", 2", 3", 4", 5", 6", 7", 8', 9", 10", 11" and 12"
Availability
- Made to order
Submittals & Downloads
PDF - Basic Ridge Cupola
Color and Material Options
Common Material Options for Cupolas
Copper is the most popular metal for cupolas. It is offered in 16 oz. and 20 oz.
Freedom Gray® (zinc / tin coated copper) is offered in 16 oz. and 20 oz.
Lead Coated Copper is offered in 16 oz. and 20 oz.
Stainless steel is offered in 24 gauge 304 2B.
Zinc is offered in 0.7 mm and 0.8 mm with a raw finish.
Other colors, materials and thickness may be available upon request. Colors displayed for reference only.
Please click here for a full selection of colors and materials offered.
