Freedom Gray Hidden Mount Strap for Plain Square or Round Downspouts
Available in 16 oz. or 20 oz. Downspout wall attachment.
Downspout straps come pre formed to fit our standard plain square or round downspouts. This bracket is designed to get installed to the wall before the installation of downspouts. After which, the legs can be screwed or riveted into the side of the downspout.
This item can be used with our standard downspout strap (Select the 1 1/2" depth option if using in conjunction with our standard downspout strap)
Custom colors, sizes and materials are available as custom items. Please, contact us for a quote.
| Downspout Size | A / Width | B / Leg | C / Depth | F / Stock Size | |
|---|---|---|---|---|---|
| 2"x3" / 3"x3" or 3" Round | 3.25" | 1.75" | 1.5" or 2"0.5" | 14" | |
| 3"x4" / 4"x4" or 4" Round | 4.25" | 2.75" | 1.5" or 2" | 19" | |
| 4"x5" / 5"x5" or 5" Round | 5.25" | 2.75" | 1.5" or 2" | 20" |
Submittals & Downloads
Color and Material Options
Common Material Options for Downspouts
Copper
Pre Patina Copper
Freedom Gray
Galvalume Plus
Galvanized Steel
Bonderized Steel
Lead Coated Copper
Zinc
Other colors, materials and thickness may be available upon request. Colors displayed for reference only.
Please click here for a full selection of colors and materials offered.
