Hidden Mount Kynar Steel Downspout Strap
Product Details
Brand: K&M Sheet Metal
leadtime: 7
24 Gauge Kynar® Steel Hidden Mount Strap for Plain Square or Round Downspouts
Available in Several colors. 24 Gauge Kynar® Steel. Downspout wall attachment.
Downspout straps come pre formed to fit our standard plain square or round downspouts. This bracket is designed to get installed to the wall before the installation of downspouts. After which, the legs can be screwed or riveted into the side of the downspout.
This item can be used with our standard downspout strap (Select the 1 1/2" depth option if using in conjunction with our standard downspout strap)
Custom colors, sizes and materials are available as custom items. Please, contact us for a quote.
| Downspout Size | A / Width | B / Leg | C / Depth | F / Stock Size | |
|---|---|---|---|---|---|
| 2"x3" / 3"x3" or 3" Round | 3.25" | 1.75" | 1.5" or 2"0.5" | 14" | |
| 3"x4" / 4"x4" or 4" Round | 4.25" | 2.75" | 1.5" or 2" | 19" | |
| 4"x5" / 5"x5" or 5" Round | 5.25" | 2.75" | 1.5" or 2" | 20" |
Submittals & Downloads
Color and Material Options
Pac Clad Standard 0.032" Kynar Aluminum and 24 Gauge Galvalume Steel Downspout Straps Common Color Options
Black Aluminum
Matte Black Steel
Charcoal Aluminum Steel
Dark Bronze Aluminum Steel
Medium Bronze Aluminum Steel
Copper Penny Aluminum Steel
Almond Aluminum Steel
Bone White Aluminum Steel
